GE...E / GE...ES / GE...ES-2RS
产品编号：GE...E 4～12
GE...ES 15～300
GE...ES-2RS 15～300
滑动磨擦副： 钢/钢
产品特点：外圈有一道轴向缝，内、外圈材料均为轴承钢，淬火，磷化，滑动表面涂敷二硫化钼。除型号后置代号为E外，其余型号内、外圈均有润滑油槽油孔，后置代号有-2RS为外圈两端带有密封圈。
使用温度范围：GE...E -50℃～+150℃
GE...ES -50℃～+150℃
GE...ES-2RS -30℃～+130℃
|
轴 承 型 号 Bearing number |
外 形 尺 寸 Dimensions mm |
额定载荷 Load ratings kN |
重 量 Weight ≈kg |
|||||||||
|
d |
D |
B |
C |
dk |
rs min |
r1s min |
α˚ ≈ |
动载荷 Dynamic |
静载荷 Static |
|||
|
GE4E |
4 |
12 |
5 |
3 |
8 |
0.3 |
0.3 |
16 |
2 |
10 |
0.003 |
|
|
GE5E |
5 |
14 |
6 |
4 |
10 |
0.3 |
0.3 |
13 |
3.4 |
17 |
0.005 |
|
|
GE6E |
6 |
14 |
6 |
4 |
10 |
0.3 |
0.3 |
13 |
3.4 |
17 |
0.004 |
|
|
GE8E |
8 |
16 |
8 |
5 |
13 |
0.3 |
0.3 |
15 |
5.5 |
27 |
0.007 |
|
|
GE10E |
10 |
19 |
9 |
6 |
16 |
0.3 |
0.3 |
12 |
8.1 |
40 |
0.011 |
|
|
GE12E |
12 |
22 |
10 |
7 |
18 |
0.3 |
0.3 |
10 |
10 |
53 |
0.017 |
|
|
GE15ES |
GE15ES-2RS |
15 |
26 |
12 |
9 |
22 |
0.3 |
0.3 |
8 |
16 |
84 |
0.026 |
|
GE17ES |
GE17ES-2RS |
17 |
30 |
14 |
10 |
25 |
0.3 |
0.3 |
10 |
21 |
106 |
0.040 |
|
GE20ES |
GE20ES-2RS |
20 |
35 |
16 |
12 |
29 |
0.3 |
0.3 |
9 |
30 |
146 |
0.064 |
|
GE25ES |
GE25ES-2RS |
25 |
42 |
20 |
16 |
35.5 |
0.6 |
0.6 |
7 |
48 |
240 |
0.115 |
|
GE30ES |
GE30ES-2RS |
30 |
47 |
22 |
18 |
40.7 |
0.6 |
0.6 |
6 |
62 |
310 |
0.149 |
|
GE35ES |
GE35ES-2RS |
35 |
55 |
25 |
20 |
47 |
0.6 |
1 |
6 |
79 |
399 |
0.228 |
|
GE40ES |
GE40ES-2RS |
40 |
62 |
28 |
22 |
53 |
0.6 |
1 |
7 |
99 |
495 |
0.318 |
|
GE45ES |
GE45ES-2RS |
45 |
68 |
32 |
25 |
60 |
0.6 |
1 |
7 |
127 |
637 |
0.421 |
|
GE50ES |
GE50ES-2RS |
50 |
75 |
35 |
28 |
66 |
0.6 |
1 |
6 |
156 |
780 |
0.562 |
|
GE55ES |
GE55ES-2RS |
55 |
85 |
40 |
32 |
74 |
0.6 |
1 |
7 |
200 |
1000 |
0.864 |
|
GE60ES |
GE60ES-2RS |
60 |
90 |
44 |
36 |
80 |
1 |
1 |
6 |
245 |
1220 |
1.03 |
|
GE70ES |
GE70ES-2RS |
70 |
105 |
49 |
40 |
92 |
1 |
1 |
6 |
313 |
1560 |
1.57 |
|
GE80ES |
GE80ES-2RS |
80 |
120 |
55 |
45 |
105 |
1 |
1 |
6 |
400 |
2000 |
2.32 |
|
GE90ES |
GE90ES-2RS |
90 |
130 |
60 |
50 |
115 |
1 |
1 |
5 |
488 |
2440 |
2.79 |
|
GE100ES |
GE100ES-2RS |
100 |
150 |
70 |
55 |
130 |
1 |
1 |
7 |
607 |
3030 |
4.44 |
|
GE110ES |
GE110ES-2RS |
110 |
160 |
70 |
55 |
140 |
1 |
1 |
6 |
654 |
3270 |
4.83 |
|
GE120ES |
GE120ES-2RS |
120 |
180 |
85 |
70 |
160 |
1 |
1 |
6 |
950 |
4750 |
8.11 |
|
GE140ES |
GE140ES-2RS |
140 |
210 |
90 |
70 |
180 |
1 |
1 |
7 |
1070 |
5350 |
11.2 |
|
GE160ES |
GE160ES-2RS |
160 |
230 |
105 |
80 |
200 |
1 |
1 |
8 |
1360 |
6800 |
14.1 |
|
GE180ES |
GE180ES-2RS |
180 |
260 |
105 |
80 |
225 |
1.1 |
1.1 |
6 |
1530 |
7650 |
18.5 |
|
GE200ES |
GE200ES-2RS |
200 |
290 |
130 |
100 |
250 |
1.1 |
1.1 |
7 |
2120 |
10600 |
28.4 |
|
GE220ES |
GE220ES-2RS |
220 |
320 |
135 |
100 |
275 |
1.1 |
1.1 |
8 |
2320 |
11600 |
35.7 |
|
GE240ES |
GE240ES-2RS |
240 |
340 |
140 |
100 |
300 |
1.1 |
1.1 |
8 |
2550 |
12700 |
39.7 |
|
GE260ES |
GE260ES-2RS |
260 |
370 |
150 |
110 |
325 |
1.1 |
1.1 |
7 |
3030 |
15190 |
51.5 |
|
GE280ES |
GE280ES-2RS |
280 |
400 |
155 |
120 |
350 |
1.1 |
1.1 |
6 |
3570 |
17850 |
64.9 |
|
GE300ES |
GE300ES-2RS |
300 |
430 |
165 |
120 |
375 |
1.1 |
1.1 |
7 |
3800 |
19100 |
77.6 |
